Thrust ball bearing 51140 MP
Quick Details
Structure: Thrust
Type: Ball
Brand Name: SKF
Bore Size: 200 mm
Outside Diameter: 250 mm
Model Number: 51140 MP
Precision Rating: P0, P6, P5, P4, P2
Seals Type: OPEN
Number of Row: Single Row
Place of Origin: Shandong, China (Mainland)
Width: 37mm
Basic dynamic load rating: 232KN
Basic static load rating: 965KN
Fatigue load limit: 31KN
Limiting speed: 1640rpm
certificate: ISO 9001:2000 , SGS , BV
clearance: C0 , C2 , C3 , C1 , C4 , C5 , C6
commitment: high quality high precision waterproof bearing
main market: Eastern Europe,Southeast Asia, South America
Thrust ball bearing 51140 MP comprise of shaft location washers, housing locating washers and brass cage assemblies. The bearings are not self-retaining; the ball and cage assembly can be fitted separatley. Bearings of series 511 & 512 have a flat housing location washer. They do not permit angular misalignment or slewing between the shaft and the housing.
Product data of Thrust ball bearing 51140 MP
d=200 mm
D=250 mm
T=37 mm
C=170 kN Basic dynamic load rating, axial
C0=655 kN Basic static load rating, axial
Cua=22.7 kN Fatigue load limit
nG=1400 r/min Limiting speed
m=4.12 kg Mass
Bearing interchangeble reference for 51140 MP
bearing 51140M
NSK bearing 51140M
NTN bearing 51140M
bearing 51140M
KOYO bearing 51140R
More bearing cross reference and interchange information, Please contact us.
